Khayti Ispat Pvt. Ltd. is now offering new hot rolled equal leg angles aimed principally for girder pylons, towers for wind power mills, power pylons and antenna pylons and many other applications.
With a leg length of up to 300 mm and material thickness from 18 up to 35 mm, other material thicknesses are possible upon agreement.
Dimensions
M = Mass per m , A= Depth of Section, B= Width of Section,T = Web thickness
T = Flange Thickness, R1 = Root radius, R2 = Leg radius, Area = Area of Section
|
Product Range |
Mass |
Sectional |
Dimensions |
||||||
|
(M) |
Area (a) |
D |
B |
t |
T |
Flange Slope |
R1 |
R2 |
|
|
Kg/m |
cm² |
mm |
mm |
mm |
mm |
deg. |
mm |
mm |
|
|
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
|
|
MB 100 |
8.90 |
11.40 |
100 |
50 |
4.70 |
7.00 |
98.00 |
9.00 |
4.50 |
|
MB 125 |
13.30 |
17.00 |
125 |
70 |
5.00 |
8.00 |
98.00 |
9.00 |
4.50 |
|
MB 150 |
15.00 |
19.10 |
150 |
75 |
5.00 |
8.00 |
98.00 |
9.00 |
4.50 |
|
MB 175 |
19.60 |
25.00 |
175 |
85 |
5.80 |
9.00 |
98.00 |
10.00 |
5.00 |
|
MB 200 |
24.20 |
30.80 |
200 |
100 |
5.70 |
10.00 |
98.00 |
11.00 |
5.50 |
|
MB 250 |
37.30 |
47.50 |
250 |
125 |
6.90 |
12.50 |
98.00 |
13.00 |
6.50 |
|
MB 300 |
46.00 |
58.60 |
300 |
140 |
7.70 |
13.10 |
98.00 |
14.00 |
7.00 |
